Description:
The 12 cu ft Disc Spreader is a professional tractor-mounted spreading machine engineered for high efficiency and versatility in modern agriculture. Designed to work seamlessly with tractors (recommended matched power: 70-150 HP) , it draws power from the tractor’s rear PTO to drive its integrated hydraulic system, ensuring stable and reliable operation even in demanding field conditions.
At the core of its design is a robust structure comprising a reinforced traction frame, welded steel frame (resistant to deformation under heavy loads), and a large-capacity fertilizer hopper (12 cu ft standard volume, customizable for specific needs). The hopper undergoes sandblasting, shot blasting, and multi-layer anti-rust coating treatments, effectively resisting corrosion from moist organic materials and extending service life . Key functional components include a dedicated hydraulic oil tank (solving the problem of unstable hydraulic performance in small tractors), high-quality hydraulic motor, precision gearbox (equipped with a built-in overload protector), double-chain feeding device, and a dual-disc spreading system.
The working principle is both efficient and intelligent: the tractor’s PTO powers the hydraulic system, which drives the hydraulic motor to push materials backward uniformly via the double-chain feeding mechanism. Simultaneously, the rear propeller shaft activates the gearbox, rotating the double discs at high speed. The discs are fitted with ladder-distributed crushing wheels and high-hardness spring manganese steel blades , which break down lumpy materials (such as manure or compost) while spreading them, ensuring uniform distribution across the target area. A manually adjustable gate at the tail of the hopper allows precise control of material output, adapting to different spreading requirements.
Specifications:
| Model | 12 |
| Capacity（m³） | 12 |
| Supporting Power | 100-150HP |
| Spreading Width（m） | 6-14 |
| Weight（kg） | 3500 |
| L*W*H(mm) | 6900×2800×2630 |
| Working Efficiency（ha/day） | 46 |
Applications:
This 12 cu ft Disc Spreader is a versatile solution for multiple scenarios and materials, making it ideal for farms, pastures, orchards, greenhouses, and even road maintenance projects:
1.Agricultural fields (paddy fields, drylands): Spreading base fertilizer (manure, organic fertilizer, granular fertilizer) before plowing, and supplementary nutrients during crop growth stages.
2.Grasslands & pastures: Distributing organic matter, lime, or mineral supplements to improve forage quality and soil fertility.
3.Specialized farming (orchards, greenhouses): Precise spreading of organic fertilizer or soil amendments without damaging crops or facilities.
4.By-product utilization: Spreading agricultural by-products such as wine trough, sugar residue, 塘渣 (pond sludge), and distiller’s grains, realizing resource recycling .
5.Auxiliary scenarios: Spreading sand or deicing materials on rural roads, or distributing bedding materials in livestock farms.
Video：
Advantages：
1.Uniform spreading & strong crushing capacity The double-disc structure with ladder-distributed blades and spring manganese steel crushing components efficiently breaks down lumpy materials, achieving a spreading uniformity rate of over 95% . The adjustable outlet and spreading width (6-10 meters) allow customization for different field sizes and crop densities.
2.Durable & low-maintenance design Equipped with agricultural special load-bearing tires (e.g., 23.1-26 model) and high-quality axles (such as Italian Adler axles) , the machine offers excellent load-bearing capacity and stability, even on uneven terrain. The anti-rust hopper, heavy-duty mining chains, and sealed hydraulic system reduce wear and tear, minimizing maintenance frequency and costs.
3.Cost-saving & eco-friendly By optimizing material utilization, it solves the problems of high fertilization costs, extensive application, and serious waste in traditional methods . It promotes organic fertilizer return to the field, improving soil structure, enhancing water and fertilizer retention capacity, and reducing environmental pollution from livestock manure.
4.Easy operation & strong adaptability The tractor-mounted design enables quick installation and disassembly, with intuitive controls for adjusting spreading volume and speed. It can handle various solid materials (powder, granules, lumps) , adapting to diverse agricultural scenarios from small family farms to large-scale cooperatives.
5.Reliable performance & safety protection The built-in overload protector in the gearbox prevents component damage from excessive loads . The stable hydraulic transmission ensures smooth operation with low failure rates, while optional side guardrails can increase loading capacity by 15% for higher productivity.
FAQ：
1.What power source does this spreader need?
It relies on the rear PTO of a tractor to power the hydraulic system and spreading mechanism.
2.Can it spread both powder and granular materials?
Yes, the double-chain + double-disc structure is suitable for both powder and granular solid materials (e.g., manure, organic fertilizer, lime).
