Description:
The automated DYP series center pivot irrigation characterize high in efficiency ,Featuring in high efficiency ,power and water saving ,the irrigation can increase yield at economical cost with the spraying uniformity coefficient up to 85%,and take advantages of the uniform application of chemical and fertilizers .The system can also work on uneven fields with slopes of up 25%.product.
Specifications:
| Main pipe diameter | 6-5/8''(168mm*3.2mm,high frequency welded steel pipe |
| Standard span | 6-5/8''(168mm)*54.5m(8 pipes) |
| King-sized span | 6-5/8''(168mm)*61.3(9 pipes) |
| Motor power | 0.75~1.5 horse power |
| Motor speed reducer | output speed of electric transmission gearbox:28~86RPM |
| Span body tower structure | Adopt "V" model tower |
| Truss Diameter | 22mm,19.1mm,17.5mm( 61.3m:22mm; 54.5m&48m: 19mm; 41m&34m:17.5mm ) |
| Collector Ring | external |
| Center Drive | USA Brand |
| Gear Box | USA Brand |
| Max Slope | 25% OR 30% |
| Tire Options | 11.2"x22.5"; 11.2"x24.5"; 11.2''x24''; 14.9"x24'' |
| Maximum Towers | 20 |
| Power Supply | 380v-460v |
Advantages：
This kind of machine is with high irrigation efficiency, low the labor tension, save water, suitable for middle and small farm to adopt. This machine has simple structure, adaptive range is wide.
Applications:
FAQ：
Q: Are you trading company or manufacturer ?
A: We are fully registered manufacturing&exporting company by Chine Export Registration Authorities with self-supported import and export right.
Q: How long is your delivery time?
A: Generally within 20 working days if the goods are in stock. Depend on the quantity of order.
Q: Whether you can support customized logo?
A: Yes, we have CE, ISO: 90001.
