Description:
The central support type sprinkler is also called pointer or circular sprinkler . Its water spray pipe is connected by thin wall galvanized steel pipes one by one, and there are many low-pressure sprinklers arranged at a certain interval.
Specifications:
| MAIN PIPE DIAMTER | 168 mm |
| STANDARD SPAN | 168mm 54.5 m with 8 PIPES |
| KING SIZE SPAN | 168mm 61.3 m with 9 PIPES |
| PIPE LENGTH | 6.7 M 22 feet |
| SPRAYER MOUNTED | The American original sprinklers series as option |
| POWER SUPPLIED | DIESEL GENERATOR OR LOCAL POWER SUPPLIED |
| SPAN BODY TOWER STRUCTURE | V model |
| THE END | LED WORKING LIGHT |
| MOTOR SPEED REDUCER | ELECTRIC TRANSMMISON GEAR BOX (AMERICAN BRAND) |
| TIRE TYPE | 14.9X24 VACCUM TIRE |
| IRRIGATION INTAKE | 1 WATER INTAKE WITH QUICK CONNECTION |
| STANDARD TRUSS HEIGHT ALLOWED | 3.2m |
| INTAKE PRESSURE | 0.2-0.35 mpa |
Advantages：
Full flow collector ring
The collector ring is mounted externally, eliminating water flow restriction.
Advanced controls
User-friendly control panels offer time-saving management and precise control.
Applications:
FAQ:
Q:What about the MOQ?
A:1 set (at least 2 spans)
Q: There are many similar unqualified products in the market, how can you make sure your quality control?
A: We have got the certificates of CE and ISO 9001, and strict production procedures are effected in our company
